Versatile Double-Sided Printed Board with 1.6mm Thickness and Min. Hole To Copper of 0.2mm

Product Description:

A Double Sided PCB, also known as Twin Layer PCB or Dual-Sided Printed Wiring Board, is a versatile and reliable option for various electronic applications. This particular product features a copper weight of 1oz, making it suitable for a wide range of circuit designs and configurations.

Utilizing standard special technology, this Double Sided PCB offers quality performance and consistency. The special technology also includes Impedance Control with a tolerance of ±10%, ensuring stable signal integrity and optimal electrical characteristics.

Designed for offline applications, this Double Sided PCB is well-suited for projects that require efficient and durable circuit boards. The offline type provides flexibility in usage and compatibility with different electronic devices and systems.

Constructed with high-quality FR4 materials, this Double Sided PCB offers excellent thermal and mechanical properties, enhancing the overall reliability and performance of the circuit board.

With its dual-sided design, this PCB provides ample space for complex circuitry and components, allowing for increased functionality and connectivity within electronic devices. The double-plated construction ensures reliable conductivity and signal transmission across both layers of the board.

Whether you are working on consumer electronics, industrial equipment, automotive systems, or any other electronic project, this Double Sided PCB is a dependable choice that meets the demands of modern circuit design and manufacturing.

Features:

• Product Name: Double Sided PCB
• Materials: FR4
• Conductor Space: 5 Mil
• Solder Resist Color: Green
• Type: Offline
• Finished Copper: 35um

Technical Parameters:

Applications:

A Double Sided PCB, also known as a Twin Layer PCB or Bi-Layer PCB, is a versatile electronic component that is suitable for a wide range of product application occasions and scenarios due to its unique attributes.

With a standard special technology, 1oz copper, and surface finishing options including HASL, OSP, ENIG, Immersion Gold, and lead-free coatings, the Double Sided PCB is ideal for offline applications where reliability and performance are crucial.

Due to its 1.6mm board thickness, the Double Sided PCB is well-suited for various scenarios, including the manufacturing of overlength PCBs where space constraints may be a concern. Its double-sided design allows for increased functionality and complexity in electronic circuits, making it perfect for applications that require multiple components and connections.

Product application occasions for the Double Sided PCB include but are not limited to:

• Industrial Control Systems: The Double Sided PCB can be used in industrial control systems where precision and durability are essential, thanks to its high-quality copper and surface finishing options.
• Consumer Electronics: From smartphones to household appliances, the Double Sided PCB is a popular choice for various consumer electronic products due to its reliability and performance.
• Automotive Electronics: In the automotive industry, the Double Sided PCB is used in vehicle control systems, entertainment systems, and more, providing the necessary functionality and stability.
• Telecommunications: The Double Sided PCB is also widely used in telecommunications equipment, such as routers, modems, and networking devices, where seamless connectivity is crucial.

In conclusion, the Double Sided PCB is a versatile electronic component with a wide range of product application occasions and scenarios, making it a reliable choice for various industries and applications.

Customization:

Enhance your project with our Extra long double-sided PCB customization services. Our Dual Layer PCB offering includes customization options such as Finished Copper: 35um, Min. Hole To Copper: 0.2mm, Number Of Layers: 2, and Materials: FR4. In addition, we provide Other Services like PCB Design and PCB Assembly to ensure your Dual-Sided Printed Wiring Board meets your specific requirements.

Support and Services:

Our Product Technical Support team is dedicated to providing assistance with any inquiries regarding our Double Sided PCB product. We offer a range of services to ensure the optimal performance and reliability of our product.
